ECO Single Bag Filter Housing

ECO Single Bag Filter Housings are the light-weight bag filter housings combine quality and value.

ECO Single bag filter housing-Stainless Steel Bag Filter Housing For Industrial Filtration

Eco Bag Filter Housing is the perfect choice for cost sensitive applications that require a reliable light weight vessel withvery good sealing capabilities. ECO Bag Filter Housing,  V-Clamp cover design, stainless steel basketsand 1, 1/2” or 2” NPT piping connections. Legs not standard,if you need the Legs,please tell us.

ECO Bag Filter Housing specification

Eco Bag Filter Housing Filtration Specification:

Inlet & Outlet: 1, 1/2” or 2” NPT

Filtration area: 0.05 & 0.1 & 0.25 & 0.5m2

Flow rate: 5/10/20/40 m3/h

Design pressure: 6 bar

Suitable working pressure : 3-4 bar

Housing material: 304SS

Filter Bag size: D4" *L8" /D4" *L14" /D7" *L17" /D7" *L32"

Optional micron rate: 1um, 5um, 10um, 25um, 50um, 100um, 150um, 200um...600um...1000um

ECO Single Bag Filter Housing

ECO Bag Filter Housing application

---Paints, Coating, Inks, Dispersions

---Water and Water Treatment

---Solvents

---Lubricants, Metalworking Fluids

---Parts Cleaning Solutions

---Pulp and Paper

---Pharmaceutical

---Food Processing

---Chemical Processing

---Edible Oils

---Potable Water, Beer, Wine

---Automotive

ECO Single Bag Filter Housing

ECO BAG FILTER HOUSING MODEL TABLE
